28
To output as VBS
Outputting via 3G-SDI
The SDI-1 output becomes 3G-SDI output.
To output in 1080/59.94P or 1080/50P
Outputting via Dual Link
The SDI-1 output is assigned to Link A, SDI-2 output to Link B.
To output in 1080/59.94P or 1080/50P
Viewfinder Screen Status
Display
Besides the video image, the viewfinder can display text and
messages showing the camera settings and operation status,
as well as items such as a center marker or safety zone
marker.
When the DISPLAY switch is set to DISPLAY
Items set to ON using the menu or related switches will be
displayed on the upper and lower edges of the screen.
a Zoom position
Indicates the approximate position of the zoom lens variator
between wide angle (0) and telephoto (99).
b Lens extender
“EX” is displayed when a lens extender is in use.
c TALK indicator
Displayed when the intercom microphone is set to ON.
d Follow focus indicator
Displayed if an offset is superimposed when follow focus is
enabled.
e 5600K mode
Displayed when 5600K is set to ON.
f Filter
Displays the type of filter currently selected. The number (1, 2,
3, 4, or 5) indicates the ND filter, and the letter (A, B, C or D)
is for the CC filter selection.
g White balance memory
Displays the currently selected white balance automatic
adjustment memory.
W:A: The WHITE BAL switch is set to A.
W:B: The WHITE BAL switch is set to B.
W:P: The WHITE BAL switch is set to PRST.
Menu page Page No. Item Setting
<TEST OUT> M11 OUTPUT VBS
DOWN CONVERTER
SELECT
VF
Menu page Page No. Item Setting
<SYSTEM
FORMAT>
M10 ACTIVE LINE 1080
(Format) 59.94P or
50P
<SDI OUT> M12 SDI-1 OUT 3G-SDI
Menu page Page No. Item Setting
<SYSTEM
FORMAT>
M10 ACTIVE LINE 1080
(Format) 59.94P or
50P
<SDI OUT> M12 SDI-1 OUT MAIN/
LINK-A
SDI-2 OUT/IN MAIN/
LINK-B
F255
12.5V
DOOR No1
EX Z55
1B
F5.6
W:A
5600K
TALK
FC OFFSET ADDED 100(FAR)
1/125
0dB
a
d
e
f
g
h
i
j
k
l
b
c
m
n
