Terminal label Description
4K 100 Hz support depends on your country/region.
HDMI IN (eARC/ARC)
To connect an audio system that supports eARC (Enhanced Audio
Return Channel) or ARC (Audio Return Channel), connect to the
HDMI port labelled “eARC/ARC” on the TV. It is a feature that sends
audio to an audio system that supports eARC/ARC through an HDMI
cable. If the audio system does not support eARC/ARC, you need to
connect with DIGITAL AUDIO OUT (OPTICAL).
Hint
There may be three tactile dots, next to the HDMI input terminal
depending on your model. Use them as a guide during installation.
or
DIGITAL AUDIO OUT (OPTICAL)
Connects to an audio system with optical audio input.
When connecting an audio system not compatible with ARC using an
HDMI cable, you need to connect an optical audio cable to the
DIGITAL AUDIO OUT (OPTICAL) to output digital sound.
For details, refer to Digital optical cable connection in Connecting an
audio system.
Note
The terminal vary depending on your model.
Optical audio output and S-CENTER SPEAKER IN share the same
terminal or have one terminal each individually (two terminals in
total).
For a model that requires sharing of one single terminal, use the
Digital audio connector adapter that comes with the TV to apply as
an optical audio output.
S-CENTER SPEAKER IN
Connects the TV and an audio device with an S-CENTER OUT
output/jack using a TV centre speaker mode cable. Before
connecting, make sure you unplug the AC power cord (mains lead) of
the TV and audio device to be connected.
For details, refer to Using the TV as a centre speaker.
Note
