14
Specifications
Specifications
Flashing in orange: Charged between 0 to 80%
Flashing in green: Charged over 80%
Lit in green: Fully charged
The charging current is automatically blocked if a battery pack other
than a lithium-ion battery pack is attached. Be sure to charge a
designated battery pack only.
Detaching a battery pack
Slide the attached battery pack in the opposite direction to that when
attaching then pull it up.
Charging time
The time to charge a completely exhausted battery pack to its full
capacity is shown below.
BP-U30: approximately 130 minutes
BP-U60: approximately 170 minutes
BP-U90: approximately 220 minutes
When an abnormality is detected
When one of the following conditions is detected during charging,
the CHARGE indicator flashes in orange and green alternately:
• After the start of charging, quick charging does not begin.
• Charging does not finish within a specified period.
• The voltage for battery charging has exceeded the specified level.
• The internal voltage has exceeded the specified level.
• The internal voltage has dropped below the specified level.
Specifications
Voltage source 100 to 240 V AC, 50/60 Hz
Power consumption 38 W
Current drain Charging: 70 VA (100 V), 88 VA (240 V)
Output Charging: 16.4 V, 1.9 A/1.5 A
DC output: 12 V, 2.0 A
Peak inrush current (1) Power ON, current probe method: 28 A
(100 V)/62 A (240 V)
(2) Hot switching inrush current, measured
in accordance with European standard
EN55103-1: 15 A (230 V)
Operating temperature Charging: 0°C to 45°C (32°F to 113°F)
DC output: −5°C to +45°C (23°F to 113°F)
Storage temperature −20°C to +60°C (−4°F to +140°F)
Dimensions (w/h/d) Approx. 128 × 45 × 98 mm
(5
1
/
8
× 1
13
/
16
× 3
7
/
8
inches) (excluding
projecting parts)
Mass Approx. 330 g (12 oz)
Supplied accessories
Operating Instructions (1)
Warranty Booklet (1)
Design and specifications are subject to change without notice.
Note
Note
Always verify that the unit is operating properly before use. SONY WILL
NOT BE LIABLE FOR DAMAGES OF ANY KIND INCLUDING, BUT
NOT LIMITED TO, COMPENSATION OR REIMBURSEMENT ON
ACCOUNT OF THE LOSS OF PRESENT OR PROSPECTIVE PROFITS
DUE TO FAILURE OF THIS UNIT, EITHER DURING THE
WARRANTY PERIOD OR AFTER EXPIRATION OF THE
WARRANTY, OR FOR ANY OTHER REASON WHATSOEVER.
