EN
45
Mount feet
Mount unit
Screw on bracket
Turn the unit upside down and make sure that it
cannot fall over during assembly. Remove all
screws from the two feet and lift up all parts.
Place the unit on the two screws through the large
hole in the wall bracket. Now move the unit in the
direction as described in the illustration to secure
the bracket to the screws. Check that the screws
are seated in the brackets by trying to pull the unit
towards you.
Screw holes into the wall at distance L1. Depen-
ding on the wall type, dowels should be used. The
screw head must be at least 5 mm away from the
wall.
lange Seite
des Fusses
min.
5 mm
