EN
44
08 - WALL MOUNTING
Make sure you maintain the required minimum clearances. Only use screws that support the weight of the unit and
are made for the appropriate wall. Also check that there is a socket in the immediate vicinity to connect the unit.
It is mandatory that this heater be installed on the four sides of the heater at the required minimum distances:
First remove the wall bracket from the back of the unit. Loosen the screws located on the top of the vertical
bars of the wall bracket. Then pull out the top bar by firmly squeezing the two top parts that are slotted into the
back casing. Slide the wall bracket downwards to remove it from the rear housing.
WARNING!
In the bathroom, hang at least
1000 mm from the shower.
In the bathroom min. 250 mm from
the floor
Mount only indoors or in an
indoor room
In a draft that affect
the setting of the
regulator could
L1
min. mm
min. mm
min.
mm
min.
mm
max.
mm
