10
3 Connecting the DHY-04V
addi�on an output noise gate operates when the telephone signal is below
the noise gate threshold control. This noise gate reduces the output gain by
34dB under no signal condi�ons.
Using The AES/EBU Input & Output
The unit is also capable of working in the digital domain by supplying AES/
EBU digital audio into the input XLR. The unit will automatically detect this
digital signal and so will change the output to a digital audio signal
synchronised to this input. The unit will treat 0dBFS to be the equivalent to
a +18dBU analogue signal. The AES lock LED will indicate when a valid AES
signal is present. Signals above -6dBFS have AGC applied to limit the
internal signal to a maximum of -6dBFS (equiv +12dBU).
Note: The earth bond at the screw terminal must be connected to a
technical earth to ensure the safe operation of the equipment under all line
conditions.
Using The Webserver To Configure Options
At this point you should refer to Chapter 6 and connect to the DHY-04V
using the webserver. Configure the IP address of the unit for your network
operation and check the available option settings in the ‘Configuration’
webpage (see Fig 6-5, ).
Using the DHY-04V
Receiving a Call
Incoming calls can be answered manually from the line connect button, or
the remote line connect switch, or automatically by enabling the auto
answer feature (settings SW4 ON), or externally via the serial or Ethernet
ports. Incoming calls simulate ringing by cadence illumination of the line
connect button. The line connect button lamp is off in the non-connected
mode and illuminated in the connected mode.
Note: The remote line hold output mimics the front panel line connect
button lamp, i.e. it flashes when ringing and is on when the line is held.
The hybrid unit now behaves as a 4-wire to 2-wire converter with signal
inputs at the mic/line input connector and telephone caller at the output
connector.
The call may be cleared by re-pressing the line connect button, or by means
of the remote divert switch, or via the serial or Ethernet ports. If the
remote caller hangs up then the call is cleared automatically.
Integrated Ringing Detector – Auto Answer
Ringing detectors can be used when you need to answer a call
automatically, for instance: If a journalist files a report to a recorder over a
telephone line, the call can be picked up after a set number of rings by the
ringing detector. The DHY-04V has a built in ring detector that is enabled by
setting SW4 on the rear panel.
Making a Call
To initiate a call, use the speed dial/ redial buttons on the front panel, or
use the serial port (directly or via SCi) or Ethernet port (directly or via the
webserver) to request a call to a specific number. When the call has been
established, the call will be handed over to the telephone hybrid unit. To
clear the line at the end of the call, press the line connect button. The line
connect button lamp is off in the non-connected mode and illuminated in
the connected mode.
Using Speed Dial Buttons
There are also 4 Speed Dial buttons on the front panel that can make calls
to 7 numbers setup via the webserver. When dialling, the unit shows the
dialling by a rotating illumination pattern on these buttons. Speed Dials 1-4
are accessed by a simple press on buttons 1-4, Speed Dials 5-7 and last
number redial are accessed by pressing and holding buttons 1-4
respectively.
