14
1 CM-CU1 Technical Specification
Rear Panel Connections
Prog, A, B, C & D Inputs: 5 x XLR-3 pin female (transformer balanced)
Comm Output: 1 x XLR-3 pin male (electronic balanced)
Talkback A, B, C & D
Outputs:
4 x XLR-3 pin male (transformer balanced)
Mix Output: 1 x XLR-3 pin male (transformer balanced)
GPIO Port: 15-way ‘D’-type socket
Mains Input: Universal filtered IEC, continuously
rated 85-264VAC, 47-63Hz, 10W
Fuse Rating: Anti-surge fuse 1A 20 x 5mm
DC Input: XLR-4 pin male 12V DC, 650mA Typical, 850mA
Maximum
24V DC, 325mA Typical, 425mA Maximum
Earth Point: M4 stud.
Equipment Type
CM-CU1 Commentator Unit, 1 Presenter
Physical Specification
Dimensions (Raw): 270mm (W) x 230mm (D) x 70mm (H - front) x
95mm (H - rear)
10.6” (W) x 9” (D) x 2.8” (H - front) x 3.7” (H -
rear)
Dimensions (Boxed): 380mm (W) x 350mm (D) x 200mm (H)
15” (W) x 13.8” (D) x 7.8” (H)
Weight: Nett: 3.3kg Gross: 4.3kg
Nett: 7.3lbs Gross: 9.4lbs
Accessories
CM-TC1 Commentator Unit Transport Case
Dimensions (Raw): 530mm (W) x 210mm (D) x 415mm (H)
20.9” (W) x 8.3” (D) x 16.3” (H)
Dimensions (Boxed): 600mm (W) x 260 (D) x 420 (H)
23.6” (W) x 10.2” (D) x 16.5” (H)
Weight: Net: 4.0kg Gross: 5.0kg
Net: 8.8lbs Gross: 11.0lbs
