CM-CU1 Technical Specification 1
Maximum Output Level: +19dBu
Frequency Response: ±0.5dB 20Hz to 22kHz Ref 0dBu @ 1kHz
Noise: -85dB Average weighting
Ref +8dBu
THD & N: <0.005% Ref. 1kHz @ +8dBu
Main Panel Operational Controls & Indicators
On-Air Button: Illuminated button with latching action
Talkback A, B, C & D
Buttons:
Illuminated buttons with selectable momentary
and/or latching action
Headphone Monitor
Controls:
Input source level adjustment potentiometers
Headphone channel selection switches
Line Input Level: Line input mode level potentiometer
PPM Meter: 21 segment display showing mix output level,
brightness level Is selectable
Limit LED: Indicates main output limiter is active, colour &
brightness level is selectable
Power LED: Indicates operating mode; normal or setup
Front Panel Operational Controls
Phantom: Switch to enable 48V microphone phantom
power
Mic Gain: Microphone gain potentiometer and range
select switch selects +20dB to +56dB or +50 to
+86dB
Rear Panel Operational Controls
On Air Lock: Switch to prevent On Air control from being
deactivated
Momentary push-button to override on air lock
T/B Gang: Switch to link operation of talkbacks A, B, C & D
T/B Gain: 0dB to +12dB
Limiter: Switch to enable limiter on mix output
Limit level adjustment potentiometer
Test Tone: Switch to enable 1 kHz line-up tone
Configuration Options – Accessible via Setup Mode
On Air Control Mode: Disabled, normal or permanently on
Talkback Button Action: Momentary, latching or both
Headphone Routing: Line-level input permanently routed/routed if
on air to Commentator headphones
Commentator input permanently routed/not
routed to headphone monitors
Line Level Input
Routing:
Line-level input permanently routed/not
routed/routed if on air to main output
Display Preferences: Limit LED colour and brightness
Button LED brightness
PPM meter LED brightness/disable
Permanent Option
Backup:
Save/load options to/from Permanent backup
or return to factory defaults
Front Panel Connections
Headphone Output: 1 x locking headphone jack socket
Microphone Input: 1 x XLR-3 pin latching female
Line Input: 1 x XLR-3 pin latching female
