Sommer ENTRAcode+ handleiding
Handleiding
Je bekijkt pagina 21 van 36
21
8.3 Querying the firmware version
and the active operating mode
NOTE
► This function is only available from version
3.0
► On the battery-operated version ENTRAco-
de+ AP, rst press the # key for 5 s to wake
the device from power-saving mode.
R
3
s
A
1
2
3
4
4
5
6
6
7
8
8
8
9
9
0
0
*
#
#
R
R
B
Querying the rmware version
A. Press and hold the R key for 3 s.
⇒ Green LED lights up and goes out after 3 s
B. Observe red and green LED.
⇒ Green and red LED blink simultaneously in accord-
ance with the firmware version
NOTE
The blinking pattern of the red and green
LED allows you to read out which operating
mode is active.
See "8.2 Unlocking the ENTRAcode+" on
page 21
Firmware version
3
Firmware version
4
Standard
mode
RD
GN
RD
GN
Extended
mode
RD
GN
RD
GN
etc.
8.2 Unlocking the ENTRAcode+
NOTE
In as-delivered state, the ENTRAcode+ is
locked and no input is possible. The device
must be unlocked before initial commission-
ing.
#
► Press and hold the # key for 5 s.
⇒ Red, green LED and backlighting
blink
⇒ Red and green LED go out
⇒ Backlighting lights up
✔ ENTRAcode+ was successfully unlocked
8. Operation / Operation for both operating modes
