User can add inverters and batteries to increase capacity. The system supports up to 6
inverters in parallel. Inverter Share a battery system.
1.6.2 Parallel System
NOTE:
In parallel-system scenarios, maximum support 6 parallel connections.
Parallel connection of different models is not supported.(Like 12K and 15K
can't be connected in parallel).
The AC-Backup port can be connected in parallel, and the single-phase
output power is 1 / 2 of the total AC power.
In parallel-system scenarios, connecting DG via ATS is recommended;
In the parallel system, each inverter is recommended to plug in the
datalogger, otherwise, the remote upgrade cannot be performed.
The parallel cable between the two inverters should not exceed 5m.
NOTE:
Single inverter noise is less than 65 dB (A), When using multiple inverters
to combine, pay attention to noise protection.
Figure 1.4 Parallel System
SolisCloud
APP Web
Phone
Master
PV Module
CT/Smart Meter Power Meter
Grid
Battery
Grid Load
Backup Load
Phone
Slave
PV Module
Power Line
Signal Line
User Manual
1. Introduction
06
