the front of the Interface. Outputs 3 & 4 can be used for miscellaneous tasks such as feeding external headphone
mixers/amps or sending signals to external effects units.
All outputs are also DC-coupled and able to send +/-5v signal to allow CV control to Semi & Modular Synths, Eurorack and
CV-enabled outboard FX.
Please Note: More information is available in the CV Control via Ableton® Live CV Tools section in this User Guide.
When using outputs 1-2 for CV output, remember the Monitor Control Knob is still affecting the signal. Some
experimentation on finding the best level for your connected CV controlled synth/FX unit may be required.
USB 2.0 Port : 'C' Type Connector
Connect this to a USB port on your computer, using one of the two cables provided in the box.
MIDI IN & OUT
The MIDI (DIN) IN & OUT allow the SSL 2+ MKII to be used as a MIDI interface. MIDI IN will receive MIDI signals from
keyboards or controllers & MIDI OUT allows MIDI information to be sent out to trigger Synths, Drum machines or any MIDI
controllable equipment you have available.
Kensington Security Slot
The K slot can be used with a Kensington Lock to secure your SSL 2+ MK II.
How-To / Application Examples
Connections Overview
The diagram below illustrates where the various elements of your studio connect to SSL 2+ MKII on the rear panel.
