6
MODBUS MAP
Basic connectivity characteristics
Default address 1
Transmission speed: 19200
Parity: EVEN
Modbus
Address
Discrete input Data
type
Range Default Observations
10002 Enable_Input BIT 0: OFF
1: ENABLE
1 Remote ON/OFF status (bridge EN-24V)
OFF: remote off
ON: remote on
10003 Rotation_sense BIT 0: CCW
1: CW
0 Motor rotation viewed from the motor cover
10004 AN_IN1_Defi nition BIT 0: 0-10Vdc
1: 4-20mA
0 J5.1
Defi nition of analogue input IN1
10005 AN_IN2_Defi nition BIT 0: 0-10Vdc
1: 4-20mA
0 J5.2
Defi nition of analogue input IN2
10006 Errors_Defi nition BIT 0: MANUAL
1: AUTO
1 Type of reset in case of error
Modbus
Address
Input register Data
type
Range Def. Observations
30002 AN_IN1_Phisical_Value 16bits 0-65535 - Motor setpoint value scaled according to Holding Register 40011
and 40012
(Valid if “Set_Point_Input=0”, Holding register)
30003 AN_IN2_Phisical_Value 16bits 0-65535 - Sensor value scaled according to Holding Register 40014 and 40015
(Valid if “Set_Point_Input=0”, Holding register)
30004 AN_IN1 16bits 0-10000 - Analogue input value IN1 (mV)
30005 AN_IN2 16bits 0-10000 - Analogue input value IN2 (mV)
30006 AN_OUT 16bits 0-10000 - Analogue output value OUT (mV)
30007 Motor_Speed 16bits 0-5000 - Motor speed (rpm)
30008 Motor_Power 16bits 0-3000 - Motor power (W)
30009 Motor_Torque 16bits 0-1000 - Motor torque (CnNm)
30010 Motor_Voltage 16bits 0-500 - Motor voltage (V)
30011 Motor_Current 16bits 0-10000 - Motor intensity (mA)
30012 BUS_Voltage 16bits 0-500 - Bus Voltage (V)
30013 BUS_Current 16bits 0-10000 - Bus Intensity (mA)
30014 Input_Voltage 16bits 0-500 - Supply voltage (V)
30015 IPM_Temperature 16bits 0-150 - IPM Temperature (°C)
30016 PCB_Temperature 16bits 0-150 - Motor internal ambient temperature (°C)
30017 Motor_Status 16bits 0-N - 0: Stop
1: Running
2: Motor alarm
3: External alarm (enable input)
30018 Actual_Alarm 16bits 0-N - 16: Low BUS voltage
32: Low BUS voltage during PTC bypass
37: Low input voltage
38: High input voltage
48: High BUS voltage
64: Overspeed
65: Motor phase fault
66: Low counter-electromotive force
80: High consumption (>1 sec.)
81: High consumption (peak), limit higher than alarm 66
96: High phase consumption
97: Intensity limitation at low speeds (<50% rpm maximum)
112: IPM temperature high (2 secs)
113: IPM instantaneous temperature high, temperature limit higher
than alarm 96
114: IPM temperature high before motor turn-on
116: Ambient temperature high (2 secs)
117: Ambient instantaneous temperature high, temperature limit
higher than alarm 114
118: Ambient temperature high before motor turn-on
122: IPM temperature read error
123: Ambient temperature read error
128: Short circuit
129: Short circuit output
Mode: RTU
Electrical interface: RS-485
Type of connector: wiring D0 – D1 – Common (GND)
DISCRETE INPUTS (read only)
INPUT REGISTERS (read only)
continue
