15
Unbalance of the airflow:
This setting could be necessary in case of:
1 – Case of an open chimney:
In this case, it’s necessary to make an airflow aportation equivalent at the stack effect airflow.
In this case there are two possibilities:
a. Make a specific air inlet. In this case ensure that it’s sealable.
b. Add an additional intake airflow using the DOMEO corresponding at the stack effect
airflow.
Follow these recommendations:
. Watch that all doors, windows, … are securely closed,
. Light the chimney fire,
. Adjust the unbalance airflow up to reach the good chimney performance
2. Case of unbalance between the intake and extract airflows:
It could be possible when one of the both ductworks is advantaged or disadvantaged.
Enter with the key and modify the unbalance value with the keys , then confirm with
the key .
This setting is done by the intake airflow compared to the extract airflow.
Volt free contact:
The electronic board is equipped with a volt free contact that allows increase to the boost airflow
controlled by an external sensor (switch, CO2 sensor, PIR sensor, humidity sensor, …). You
can change the position of the contact:
NO = Normally Open
NC = Normally Closed
Enter with the key and move to the different options with the keys .
Then confirm with the key .
Pre-heating battery:
In case of a connected pre-heating battery. Enter with the key , modify the option with the
keys .
Then confirm with the key .
Post-heating battery:
In case of a connected post-heating battery. Enter with the key , modify the option with the
keys .
Then confirm with the key .
Air quality sensor (0-10V):
In case of a connected sensor (CO2, VOC, RH, …). Enter with the key , modify the option
with the keys .
Then confirm with the key .
Connection Type:
Adjust A or B depending on the connection Type
Enter with the key , modify the option with the keys .
Then confirm with the key .
Units:
You can choose the airflow unit in m
3
/hour or litres/second.
Enter with the key and choose the unit with the keys , then confirm with the key .
