27
español english français portuguese deutsch italiano
Function Working process
Fry
(manual
function)
Press the function button in the standby state (digital display show “ON”) or
work to enter the fry function, the display shows the temperature as 200ºC.
This function has 8 levels of adjustable temperature, respectively
100-120-140-160-180-200-220-240ºC (For both side of hobs), you can press
Up or Down to select the appropriate temperature range. You can press the
timer key to set the shutdown time. The setting range is "0:01 - 4:00".
Hot pot
(manual
function)
Press the Press the function key in standby state (digital display show “ON”) or work to
enter the hot pot function, the display shows the power level 2000W. This function has 8
levels of adjustable power, 300-600-1000-1200-1400-1600-1800-2000W (for left side of
Hob or 2000W power) and 300-600-800-1000-1200-1300-1400-1500W (For Right side or
with 1500W power), you can press Up or Down to select the appropriate power level. You
can press the timer key to set the shutdown time. The setting range is "0:01 - 4:00".
Barbecue
(manual
function)
Press the function button in the standby state (digital display show “ON”) or
work to enter the Barbecue function, the display shows the temperature as
240ºC. This function has 8 levels of adjustable temperature, respectively
100-120-140-160-180-200-220-240ºC (for both side of hobs), you can press
Up or Down to select the ap-propriate temperature range. You can press the
timer key to set the shutdown time. The setting range is "0:01 - 4:00".
Steam
(automatic
function)
Press the function key in the standby state (digital display show “ON”) or work to enter
the steam function, the display shows the power level 1800W. This function is an
automatic function, the machine will automatically complete the cooking process, first it
will work on 1800W for 20 minutes, th n automatically switch to medium 400W for 70
minutes. After the program is completed, it will automatically shut down. The default
working time is 90 minutes. The power level & shutdown timer cannot be adjusted. Press
the timer/preset button to set the Switch-on time, the setting range is "0:01-24:00".
Note: for Right side hob default power is 1400W, with rest of the details same as Left
hand side hob.
Soup (automatic
function)
Press the soup key in the standby state (digital display show “ON”) or work to enter the
soup function, the display shows the power level 1600W. This function is an automatic
function, the machine will automatically complete the cooking process, it starts on 1600W
for 20 minutes, then automatically switch to 800W for 100 minutes. After the program is
completed, it will automatically shut down. The default working time is 120 minutes (it
cannot be changed). The power level cannot be adjusted during work. Press the timer/
preset button to set the Switch-on time, the setting range is "0:01-24:00".
Note: For Right hand side hob default power is 1300W, with rest of the details same as
Left hand side hob.
Water (automa-
tic function)
The default power is 2000W for water boiling, and the default timer is 45 minutes for
automatic shutdown which cannot be changed. Press the timer/preset button to set the
Switch-on time, the setting range is "0:01-24:00".
Note: for Right hand side hob the default power is 1500W, with default time 45minutes.
Milk (automatic
function)
The default power is 80ºC for milk boiling, and the default timer is 20
minutes for automatic shutdown which cannot be changed.
Press the timer/preset button to set the Switch-on time, the setting range is
"0:01-24:00".
High temperatu-
re tips
After working, when the temperature of the surface is higher than 60ºC, the
high temperature indicator light will be on to remind the user that the surface
is high temperature, please do not touch it. When the temperature of the sur-
face is lower than 60ºC, the high temperature indicator light goes out.
Note: The fan start working when the unit temperature exceeds 60 degrees, and once the
temperature lower than 60 degrees, the fan stop working.
Levels
1
2
3
4
5
6
7
8
Power(W) 300 600
1000/800
1200/1000 1400/1200 1600/1300 1800/1400 2000/1500
Temp (ºC) 100 120 140 160 180 200 220 240
