Chapter 4 Connecting computers and other devices
docs.smarttech.com/kb/171554 45
Resolution Input aspect ratio Mode Refresh rate
1280 × 720 16:9 HD / 720p 59.94 Hz / 60 Hz
50 Hz
29.97 Hz / 30 Hz
25 Hz
23.98 Hz / 24 Hz
720 × 480 16:9 480p (DVD Player) 60 Hz
This table presents the recommend resolutions and refresh rates for the display’s VGA input:
Resolution Input aspect ratio Mode Refresh rate
1920 × 1080 16:9 [N/A] 60.000 Hz
1600 × 1200 4:3 [N/A] 60.000 Hz
1360 × 768 16:9 [N/A] 60.015 Hz
1280 × 1024 5:4 SXGA 60 60.020 Hz
1024 × 768 4:3 XGA 60
XGA 70
XGA 75
60.004 Hz
70.069 Hz
75.029 Hz
800 × 600 4:3 SVGA 60
SVGA 72
SVGA 75
60.317 Hz
72.188 Hz
75.000 Hz
640 × 480 4:3 VGA 60 59.940 Hz
If possible, set connected computers to these resolutions and refresh rates. See the connected
computers’ operating system documentation for instructions.
Connecting a SMART OPS PC module
If your organization has purchased a SMART OPS PC module, you or your
organization’s installers can install the module in the display’s accessory slot
following the OPS PC module’s installation instructions
(docs.smarttech.com/kb/171775 or docs.smarttech.com/kb/171544). You can
then view the OPS PC module’s input on the display.
For more information about SMART OPS PC modules, see the
SMART OPS PC modules user guide
(docs.smarttech.com/kb/171747).
