INTRODUCTION

Active Imaging HD (Thru-Hull) transducers allow:

• Side imaging (SideScan) to show underwater structure to either side of your vessel

• Down imaging (DownScan) to show underwater structure beneath your vessel

• CHIRP sonar

• DownScan FishReveal

• SideScan FishReveal, when connected to a S3100 or S3100H sonar module (sold separately).

The transducers come with fairing blocks that you cut to customise the installation to the hull of your boat.

The Active Imaging HD (Thru-Hull, Dual) system has two transducers and two fairing blocks, intended to be

installed on each side of the boat’s keel. This enables SideScan imaging for a boat whose hull obstructs side

beams from a single transducer.

Compability

Active Imaging HD (Thru-Hull) transducers are directly compatible with the following multi-function

displays:

• Lowrance HDS Pro

• Simrad

NSS 4

¼ Note: To use SideScan FishReveal, you need a S3100 or S3100H sonar module.

The multi-function displays listed below support Active Imaging HD (Thru-Hull) transducers if you install a

S3100 or S3100H sonar module:

• Lowrance HDS Live, HDS Carbon, and Elite FS.

• Simrad

NSS Evo 3, NSS Evo 3S, NSO Evo 3, and NSO Evo 3S.

Refer to the Lowrance and Simrad

websites for more information.

Sonar performance

The choice, location, and installation of transducers and other components of the system are critical to the

performance of the system. If in doubt, consult your Lowrance or Simrad

dealer.

Refer to the documentation for your multi-function display for instructions about how to operate the

transducer and interpret the display.

Safety

Never use this instrument as the sole means of gauging depth or other conditions for swimming or diving.

To reduce the risk of misusing or misinterpreting this instrument, you must read and understand all aspects

of the installation manual. This manual should be used in conjunction with the installation manual provided

with your multi-function display.
