3
CONTENTS
4 Introduction
5 In the box
5 Active Imaging HD (Thru-Hull, Single)
6 Active Imaging HD (Thru-Hull, Dual)
7 Tools and materials required
8 System overview
8 Wiring guidelines
9 Connect via sonar module
10 Connect directly to a compatible multi-function display
10 Dual installation
11 Mounting location
11 Hull material
11 Location guidelines
11 Select location
14 Fairing blocks
15 Measure hull deadrise
16 Mount fairing block for cutting
17 Cut fairing block
20 Installation
20 Drill holes in hull
21 Fit anti-rotation stud
21 Dry t and mask
23 Attach transducer to fairing block
24 Attach assembly to hull
25 Fit isolation sleeves
26 Install top of fairing block
27 Fit washers and nuts
27 Test for leaks
28 Dimensions
29 Technical specications
30 Maintenance
