13
2.9.2 Room Thermostat and/or Timer
(clean contact)
The heating demand can be controlled
by a thermostat and/or timer (TA) con-
nected to CN6 terminals 7-8 (see fig 11),
after having removed the existing bridge.
The control being used must be of a
class conforming to the standard EN
607301 (clean electrical contact).
2.9.3 Remote control SIME HOME
connection (optional)
The heating demand can be controlled
by use of remote control unit SIME
HOME (code 8092280/81)
The remote control unit allows for com-
plete control, except lockout reset.
The generator will display CR.
For installation and use of the control
follow the instructions in the package.
NOTE, Ensure PAR 10 set to 1 (PAR 10
= 1)
2.9.4 External Sensor (8094101)
An external sensor (code 8091401) can
be connected, which can automatically
regulate the flow temperature value of
the cascade delivery according to the
external temperature.
For installation follow the instructions
in the package. It is possible to make
corrections to the values by adjustment
of PAR 11.
2.9.5 Heat Demand by 230v
The heat demand can be controlled by
230v applied to terminal 14 of CN7, and
removal of the bridge on CN6 terminals
7 & 8.
2.9.6 BMS (Building Management
Systems)
The cascade of generators can be con-
trolled by a BMS signal, and should be
connected as shown in fig 11.
Set PAR 14 according to the maximum
(10v) flow temperature required.
