42
Order code: 40101
Polar 340 WashFX IP65 Moving Head
SSP
25CH
TOUR
30CH
TR16
37CH
Function
Value
Setting
150–154
Pastel orange
155–159
Cream
160–164
Melon yellow
165–169
Luminous orange
170–174
Luminous yellow
175–255
No function
22
27
34
Ring Color Effects
000–009
No function
010–023
FX 1
024–037
FX 2
038–051
FX 3
052–065
FX 4
066–079
FX 5
080–093
FX 6
094–107
FX 7
108–121
FX 8
122–135
FX 9
136–149
FX 10
150–163
FX 11
164–177
FX 12
178–191
FX 13
192–205
FX 14
206–219
FX 15
220–233
FX 16
234–247
FX 17
248–255
No function
23
28
35
Ring Color Effects Speed
000–255
Speed adjustment, from slow to fast
24
29
36
Ring Dimmer
000–255
From low to high intensity (0–100 %)
25
30
37
Control
000–009
No function
010–019
Blackout Pan/Tilt movement ON
020–029
Blackout Pan/Tilt movement OFF
030–059
DIM 0
060–069
DIM 1
070–079
DIM 2
080–089
DIM 3
090–099
DIM 4
100–139
PWM 1200 Hz
140–149
PWM 2400 Hz (2 KHz)
150–159
PWM 4000 Hz (2,4 KHz)
160–169
PWM 6000 Hz
170–179
PWM 25000 Hz
180–189
Studio (Slow)
190–199
Power (Fast)
200–209
Live (Auto)
210–219
Pan/Tilt reset
220–229
Zoom reset
230–239
All reset
240–255
No function
Notes:
● Make sure the Master Dimmer channel for the respective LEDs (Peripheral/Beam, Center, Ring) is
open in order to use the rest of the LEDs’ functionalities.
● You need first to select a color before running the beam pixel effects with user selectable colors.
Select values for red, green, blue and white in the respective channels for the Peripheral/Beam LEDs,
before choosing a built-in program.
