43
Order code: 40101
Polar 340 WashFX IP65 Moving Head
HSIC (27 channels), CMY (31 channels), PIXEL (52 channels)
HSIC
27CH
CMY
31CH
PIXEL
52CH
Function
Value
Setting
1
1
1
Pan
000–255
Pan adjustment 0°–540°
2
2
2
Pan, Fine
000–255
Pan adjustment, 16-bit
3
3
3
Tilt
000–255
Tilt adjustment 0°–270°
4
4
4
Tilt, Fine
000–255
Tilt adjustment, 16-bit
5
5
5
Pan/Tilt Speed
000–255
From fast to slow
Peripheral LEDs (Beam)
6
Beam Cyan
000–255
From low to high intensity (0–100 %)
7
Beam Magenta
000–255
From low to high intensity (0–100 %)
8
Beam Yellow
000–255
From low to high intensity (0–100 %)
9
Beam Master Dimmer
000–255
From low to high intensity (0–100 %)
6
Beam Color Intensity
000–255
From low to high intensity (0–100 %)
7
Beam Color Hue
000–255
Hue adjustment (0–100 %)
8
Beam Color Hue Fine
000–255
Fine adjustment
9
Beam Color Saturation
000–255
Saturation adjustment (0–100 %)
10
Beam CCT
000–010
No function
011–028
1800 K
029–046
2200 K
047–064
2700 K
065–082
3000 K
083–100
3200 K
101–118
3500 K
119–136
4000 K
137–154
4200 K
155–172
4500 K
173–190
5600 K
191–208
6000 K
209–226
6500 K
227–244
7200 K
245–255
8000 K
11
10
Beam Strobe
000–009
No function
010–099
From low to high frequency (0–25 Hz)
100–109
No function
110–179
Pulse strobe, from low to high rate
180–189
No function
190–255
Random strobe, from low to high rate
11
Beam Color Macros
000–010
No function
011–030
Cyan 100 % / Magenta up / Yellow 0 %
031–050
Cyan down / Magenta 100 % /
Yellow 0 %
051–070
Cyan 0 % / Magenta 100 % / Yellow up
071–090
Cyan 0 % / Magenta down /
Yellow 100 %
