13
Order code: 40101
Polar 340 WashFX IP65 Moving Head
Multiple Polars (DMX/RDM Control)
01) Fasten the effect light to a firm trussing or mount it on flat surface. Leave at least 1,3 m on all sides
for air circulation.
02) Secure the device with a safety cable (order code 70454 / 70456).
03) Use a 5-pin DMX cable to connect the Polar and other devices.
04) Link the units as shown in Fig. 08. Connect a light controller to the first unit's DMX "in" socket, using a
DMX cable. Connect the first unit’s "out" socket with the second unit's "in" socket, using a DMX
cable. Repeat this process to link the rest of the units.
05) Supply electric power: Plug electric mains power cords into each unit's power IN socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Fig. 08
Note: Link all cables before connecting electric power
