7
Ordercode: 40032
Phantom 180 Wash
Backside
Fig. 02
04) 3-pin DMX signal connector IN
05) 3-pin DMX signal connector OUT
06) Built-in microphone
07) Fuse F4AL/250V
08) Ground/earth connection
09) 100–240 V Pro power connector IN (Blue)
10) 100–240 V Pro power connector OUT (Gray)
Installation
Remove all packing materials from the Phantom 180 Wash. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Setup and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 110V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
