6
Ordercode: 40032
Phantom 180 Wash
Description of the device
Features
The Phantom 180 Wash is a moving head with high output and great effects.
● Input voltage: 100–240 V AC, 50/60 Hz
● Power consumption: 200 W
● Light source: 12 x 15W RGBW LEDs
● Light output: 14200 lux (7°) @ 3 m
● Dimmer: 0–100 %
● Strobe: 0–20 Hz
● Zoom: Motorized
● Beam angle: 7–50° (motorized)
● DMX control: via standard DMX controller
● DMX channels: 14, 29 channels
● Onboard: LCD display for easy setup
● Built-in automatic programs + built-in sound-activated programs
● Reverse Pan/Tilt movement
● Special: Pan/Tilt movement blackout
● Pan: 0–540º, Tilt: 0–270º
● Pan/Tilt resolution: 16 bit
● Control: Auto, Manual, Sound-controlled, Master/Slave, DMX-512
● Housing: Metal & flame-retardant plastic
● Cooling: Cooling fan
● IP rating: IP20
● Color: White
● Connection: 3-pin XLR IN/OUT, Pro power connector IN/OUT
● Fuse: F4AL/250V
● Dimensions: 290 x 200 x 366 mm (LxWxH)
● Weight: 8,2 kg
Frontside
Fig. 01
01) 12 x 15W RGBW LEDs
02) LCD display + control buttons
03) Safety eye
