7
Ordercode: 42589
Compact Par 18 Q4
Description of the device
Features
The Showtec Compact Par 18 Q4 is a powerful Parcan equipped with 18 x 7W RGBW LEDs. Because of its
optimized lenses, the Compact Par 18 Q4 produces a bright beam with vivid colours and excellent colour
mixing capabilities. Common connectors enable a perfect fit in any gig or tour.
● Compact Design
● Convection Cooling
● Easy Linking of Power and DMX
● RGBW LED Source
● Double bracket
● Input voltage: 100-240V, 50/60Hz
● Built-in microphone
● Refresh rate: 12 kHz
● Power consumption: 132W
● DMX channels: 4,6 or 10 channels
● 4-digit LED display for easy setup
● Light source: 18 x 7W RGBW LED
● Lux @2m: 10000
● Control modes: Auto, Static color/Manual, Sound-controlled, Master/Slave, DMX
● Control protocol: DMX-512
● Dimmer: 0-100%
● Strobe: 0-20Hz
● Beam Angle: 15°
● Protection rate: IP-20
● Housing: Die-cast Aluminium
● Cooling: Convection
● Connections: Pro Power in- & output and 3-pin + 5-pin XLR IN & OUT
● Ambient Temp.: -10 ~ 40 °C
● Certification: CE
● Fuse T2A/250V
● Dimensions: 300 x 131 x 313 mm (LxWxH)
● Weight: 5,52 kg incl. barndoor holder (5,22 kg excl. barndoor holder)
Frontside
Fig. 01
01) 18 x 7W RGBW LED
02) Adjustment screw
03) Mounting bracket
