5.4. Change the Transmitter/Receiver Mode
The AirDrive 2.4 IP, 3-pin XLR has a set-up mode and a use mode. In the set-up mode, the transmission protocol
of the device can be changed. In the use mode, the connection between devices can be set up.
To change the transmission protocol, follow the steps below:
01) Press and hold the mode button (01) until the mode LED indicator (06) lights up white.01)
02) Release the mode button (01) when the mode LED indicator (06) lights up white. The AirDrive 2.4 IP, 3-pin02)
XLR is now in set-up mode.
03)
Press the mode button (01) to cycle through the 3 transmission protocols:
03)
• Green:
W-DMX Receive mode
•
• Blue:
W-DMX G3 Transmit mode
•
• Purple:
W-DMX G4 Transmit mode
•
04)
When you have selected the right mode, press and hold the mode button (01) until the mode LED
04)
indicator(06) lights up white. The device is now in use mode.
Note:
The AirDrive 2.4 IP, 3-pin XLR remembers the selection even after shutting down the device or disconnecting the
power supply.
5.5.
Connecting and Disconnecting Multiple Devices
In the G3 or G4 Transmit mode, the AirDrive 2.4 IP, 3-pin XLR that is used as a transmitter, can be connected to
all active receivers within range that are not yet connected:
Press the mode button (01) on the transmitter to connect it to all powered receivers that are within range. The
mode LED indicator (06) starts flashing fast to indicate the connecting procedure. The mode LED indicator (06)
stops flashing once the devices are connected.
To disconnect all receivers that are connected to a transmitter device:
Press and hold the mode button (01) on the transmitter until the mode LED indicator (06) flashes red (at least 3
seconds). All active receivers within range are disconnected.
5.6.
Restore Factory Settings
To restore the device to the factory settings, follow the steps below:
01) Press and hold the mode button (01) until the mode LED indicator (06) flashes blue.01)
02) When the mode LED indicator (06) flashes blue, release the mode button (01). The mode LED indicator (06)02)
flashes red, green and blue and then lights up red to confirm that the factory settings are restored.
5.7.
DMX Connection
5.7.1. DMX-512 Protocol
The AirDrive 2.4 IP, 3-pin XLR has 3-pin DMX signal IN and OUT connectors.
The pin assignment is as follows: pin 1 (ground), pin 2 (-), pin 3 (+).
Devices on a serial data link must be daisy-chained in a single line. The number of devices that you can
control on one data link is limited by the combined number of the DMX channels of the connected
devices and the 512 channels available in one DMX universe.
To comply with the TIA-485 standard, no more than 32 devices should be connected on one data link. Inorder
to connect more than 32 devices on one data link, you must use a DMX optically isolated splitter/booster,
otherwise this may result in deterioration of the DMX signal.
Note:
• Maximum recommended DMX data link distance: 300 m•
• Maximum recommended number of devices on a DMX data link: 32 devices•
20
c
Product code: 50266
AirDrive 2.4 IP, 3-pin XLR
