English - 14
Anchor points positions: 8 x 8 frame set
600 mm 600 mm 1200 mm 600 mm 600 mm
337.5 mm
337.5 mm
337.5 mm
337.5 mm
337.5 mm
337.5 mm
337.5 mm
Anchor points number and positions
Frame set 4×4 5×5 6×6 8×8
Anchor points
(horizontal x vertical)
3×4 4×5 5×6 6×8
Horizontal distance 600 mm 600 mm 600 mm Distance center: 1200 mm
Others: 600 mm equally
Vertical distance 337.5 mm 337.5 mm 337.5 mm 337.5 mm
Anchor size Ø10 mm Ø10 mm Ø10 mm Ø10 mm
3. Make the holes at the anchor positions
• Make holes at the anchor positions using a suitable tool.
• Use screw anchors/anchor plugs as required.
• Remove the dust or dirt, and wipe off any drilling chips and dust.
