English - 13
2. Mark the positions of the anchor points on the wall
• Mark the positions of the holes you will make for the anchor points (refer to the figures below and the
“Anchor points number and positions” table on the next page).
• Before making the holes, check the verticality of the marks using a spirit level or a laser line level.
(We recommend using a laser line level is recommended for accuracy.)
Anchor points positions: 4 x 4 frame set
600 mm 600 mm
337.5 mm
337.5 mm
337.5 mm
Anchor points positions: 5 x 5 frame set
600 mm 600 mm 600 mm
337.5 mm
337.5 mm
337.5 mm
337.5 mm
Anchor points positions: 6 x 6 frame set
600 mm 600 mm 600 mm 600 mm
337.5 mm
337.5 mm
337.5 mm
337.5 mm
337.5 mm
