17
We recommend cleaning your water tank and misting hose with unscented soap and water every 3 months or as needed. Ensure you empty and
dry the water tank and misting hose after every use.
We recommend cleaning the misting nozzles every 12 months or as needed. Using harder water will require more frequent cleaning. To clean
the misting nozzles:
We recommend cleaning the fan every 6 months or as needed.
If grille screw, bolt, or Hex Key have been lost, see the Hardware Specs section for information on how to replace any hardware.
MAINTENANCE
• LOCK MODE must be activated prior to performing maintenance. This will temporarily block all fan functions until
deactivated. Lock mode prevents the fan from accidentally powering on.
1. Turn on Lock mode before
performing maintenance
for safety. To activate, hold
down the Oscillation icon on
the Fan Head for
8 seconds.
2. Place the fan upright on a flat,
level surface in tabletop mode.
Use the Phillips-head end of
the Hex Key to remove the
screw at the bottom of the
Fan Grille. Set screw aside.
3. Rotate the Fan Grille
counterclockwise to remove
it from the fan head. Set
grille aside.
4. Remove the Fan Blade Cap.
Hold the Fan Blades in place
while rotating the fan blade
cap clockwise to remove it
from the shaft.
5. Remove the Fan Blades by
gently pulling them out.
With a slightly damp cloth,
wipe down the interior parts
of the fan.
8. Rotate the Fan Grille
clockwise to secure it
to the fan head.
6. Carefully replace
the Blades onto
the center shaft.
9. Place the fan upright on a
flat, level surface. Use the
Phillips-head end of your
Hex Key to replace and
tighten the screw at the
bottom of the Fan Grille.
7. Reinstall the fan blade cap.
Hold the fan blades in place
while rotating the fan blade
cap counterclockwise to
reinstall it to the shaft.
10. Turn o Lock Mode
by holding down the
oscillation icon
on the fan head for
8 seconds.
1. Carefully remove
each brass nozzle.
CAUTION: Residual
pressure may remain in
the misting system.
2. To remove a
nozzle, twist it
counterclockwise. DO
NOT use a wrench
or any other tool.
WARNING: CHOKING
HAZARD. Keep
nozzles out of the
reach of children.
3. Soak the nozzles in a
solution of undiluted
distilled white vinegar
(5% acetic acid by
volume) to loosen
debris that may be
clogging or restricting
water flow. DO NOT
soak the nozzles for
more than 2 hours.
4. After soaking the
nozzles in the solution,
rinse them thoroughly
with water.
5. Carefully reinstall each
nozzle by twisting
clockwise until you
feel resistance.
5 6 7
1 2 3 4
Hold for 8 seconds
Lights will blink
three times when
Lock mode has
been activated
9
10
Hold for 8 seconds
Lights will display
the Power On
pattern when
Lock mode has
been deactivated.
8
