PRO 111 / PRO 115 – Pt100 thermometers
Page 13 of 25
6.1 Menu structure
The menu structure is shown below; each item is preceded by the level according to the bar
symbology shown on the display.
MENU
DESCRIPTION
‒ Measures list
Selection of the quantities to display and log
‒ Recording
Only PRO 115
= Start recording
Logging start
= Set interval
Setting of logging interval: 1/2/5/10/15/30 s, 1/2/5/10/15/30 min, 1 h
‒ Chart setup
Setting of the measurement graphical display
= Channel select
Selection of parameters to be displayed graphically (selectable from those
enabled in the "Measures list" menu)
= Chart interval
Chart measurement interval: 1/2/5/10/15/30 s, 1/2/5/10 min
‒ USB mode
Configurable only in PRO 115 between COM interface (for logging and
serial communication) or Mass storage (for viewing logging files from
PC). In PRO 111 the mode is always COM interface.
‒ Alarm settings
Type of alarm signaling: Off, acoustical (buzzer) and/or optical (flashing
backlight and red flashing status LED)
‒ Settings
= Device info
Displaying of instrument info (model, S/N, FW revision, …)
= Backlight
Backlight configuration
≡ BL activation
Backlight duration: Off, 5 s, 30 s, 1 min, always On
≡ BL intensity
Backlight intensity: Low, Medium, High
= Auto-off
Auto-off setting: Off, 30 min, 1/2/4/6/12 h
= Date & time
Setting of date and time (yyyy-mm-dd hh:mm:ss)
= Time zone
UTC or CET time zone setting
= Language
Selection of the menu language
= Dark mode
Black background enabling/disabling
= Factory reset
Reset to factory settings
‒ Pt100
Measurement settings
= Measures units
Setting of the unit of measurement: °C, °F, K
= Alerting
Alarm thresholds enabling/disabling
= Min. alarm
(*)
Lower alarm threshold (alarm if measure < threshold)
= Max. alarm
(*)
Upper alarm threshold (alarm if measure > threshold)
= Hysteresis
(*)
Thresholds hysteresis
= Calibration
Setting of the Callendar-Van Dusen (CVD) equation parameters
≡ R0
Parameter R
0
≡ exponent for A
Exponent of the CVD equation term related to coefficient A
≡ A
Coefficient A
≡ exponent for B
Exponent of the CVD equation term related to coefficient B
≡ B
Coefficient B
≡ exponent for C
Exponent of the CVD equation term related to coefficient C
≡ C
Coefficient C
= Correction
Measurement adjustment
≡ Zero point
Offset adjustment
≡ Gradient
Slope adjustment
= Probe info
Information on the probe
