HL- M1120LD INSTRUCTION MANUAL(UPDATED: 2/27/24)
4
Motorized rubber conveyor with speed control
Capable of speeds up to 394 inches/minute
Includes stainless steel pedestal with locking casters
How Does the Band Sealer Work?
Our band sealers are comprised of a stainless steel frame, speed adjusting
mechanism, sealing temperature control system and transmission system. Turning
on the heat for the band sealer will cause a rapid rise in the temperature of the heating
blocks. Required temperature and speed can be adjusted via the temperature
controller and speed adjusting device. Plastic material to be sealed is placed on the
guide and conveyor. Conveyor will then take the material between the two heating blocks to fuse the
material together. Material will then pass through the cooling blocks to allow the material to congeal.
Finally, a photoelectric sensor will direct the dry ink coder to print a clear and legible print at the seal line.
The motor drives the sealing belts, drive belts and conveyor simultaneously.
Specifications
HL-M1120LD
HL-M1120LD_LtoR
Power
110V/60Hz
Motor Power
230W (1/3 HP)
Sealing Power
300W x 2
Sealing Speed
0-394 inches/minutes
Sealing Width
10mm
Temperature Range
0-300˚C (572˚F)
Feed Direction
Right to Left
Left to Right
Conveyor Size
55" x 10"
Max Conveyor Load
33-lbs
Min/Max Height of
Bag
3.9" / 27.0"
Printing Heating
Power
40 x 2 (W)
Character Size
3x5x7mm / 18PT – 2 lines
2x3x7mm / 10.5PT – 3 lines (additional option available)
Printing Colors
Black (Option: White)
Dimensions
57" x 27" x 58"
Weight
450lbs
Basic
Principles
HL-M1120LD is easy
to use. To seal, adjust
temperature and place
bag on conveyor
