HL- M1120LD INSTRUCTION MANUAL(UPDATED: 2/27/24)
3
Introduction
Our band sealers are equipped with electronic temperature controllers and variable speed conveyors to seal
all types of thermoplastic materials (PP, PE, stand up pouches, gusseted bags, moisture barrier bags, etc.).
Seals are created using PTFE bands which maintain high seal quality and produce consistently strong, clean
seals on all heat sealable bags. Because bags are placed on a conveyor system, the width of the bag does
not matter. These versatile machines offer several adjustments which allow them to be used for a wide
range of applications. These machines are used extensively in the food, medical, chemical, cosmetic, and
electronic industries.
The HL-M1120LD is a standalone unit with locking casters providing easy mobility for the band sealer.
The vertical configuration of the sealer makes the unit ideal for packaging small solid products (ex: powders,
grains, coffee) and liquids. In addition, sealing using the vertical configuration also works best with stand
up pouches.
The HL-M1120LD band sealer adopts dry ink coding designed to print date and lot codes at the seal line.
Ink dries instantly upon contact with packaging materials and produces clear and legible characters. For
HL-M1120LD, the standard font size is 18PT which allows for two-line printing. An optional 10.5PT font
size which allows for three-line printing can be purchased separately. Please ask your distributor for more
information.
Features of the HL-M1120LD Band Sealer
Your band sealer is equipped with a wide range of standard features and capabilities.
Simple to use – minimal operator training
Fast warm up time
Unit feeds right to left
Rust inhibiting stainless steel construction
Equipped with bag entry guide for easy bag feeding and straight seals
Industrial grade safety emergency stop switch
10amp protection power surge breaker
Equipped with photo sensor for optimal printing precision
Dry ink coder for printing characters at the seal line
Wide seal (8mm) to assure airtight seal
PTFE sealing belts
Extended forced-air cooling system with extra wide cooling bars and 6 heat transfer orifices
One pair of brass sealing bars
Sealing method – constant heat
Adjustable 2-way pulley system for optimal stability and embossing clarity
Knurled pressure rolls with variable pressure adjustment
PID digital temperature controller 0-300˚C (572˚F) with dual alphanumeric displays (target & current
temperature)
Scan QR Code for
Video Demo
