HL- M1120LD INSTRUCTION MANUAL(UPDATED: 2/27/24)
46
Troubleshooting
Changing Emergency Stop
*Always unplug the unit from the power source when making adjustments.**
Problem: The emergency stop (Part #BS-22A_Gen3.0) needs to be replaced
For our smaller band sealers (CBS-880, FR-770, HL-M810, FRM-1010 units), remove the control panel plate
from the band sealer. Place the control panel on top of the band sealer for better viewing.
For our larger band sealers (FRM-1120C, FRS-1120W, HL-M1120LD units), remove the control box cover
to access the back of the control panel.
1. To remove Gen 3.0 emergency stop, click the yellow tab in release position.
Locked position
Release Position
2. Remove the contact block from the push button. The push button can be removed by loosening the
black nut.
