HL- M1120LD INSTRUCTION MANUAL(UPDATED: 2/27/24)
45
Figure 46. Turbocase (Gear Box Assembly)
Item #
Part #
Quantity Description Comments
HL-M1120LD-30_Gen1.0 1 Gear Box Assembly (Turbocase) Includes #1-29
HL-M1120LD-30_Gen2.0 1 Gear Box Assembly (Turbocase) Includes #1-29
1 HL-M1120LD-30-1 1 Vertical Shaft Bearing Seat
2 Bearing_61902ZZ 2 Deep Groove Ball Bearing 61902ZZ (φ15 x φ28 x 7)
3 HL-M1120LD-30-3 1 Vertical Shaft Spacer(2)
4 HL-M1120LD-30-4 1 Helical Gear I
5 HL-M1120LD-30-5 1 Gear Box Vertical Shaft
6 HL-M1120LD-30-6 1 Vertical Shaft Spacer (1)
7 1 Gear Box Upper Cover
8 2 Coupling I
9 1 Coupling II
10 5 Deep Groove Ball Bearing
11 1 Middle Shaft Spacer Ring I
12 1 Gear Box Middle Shaft
13 1
Helical Gear II
14 2 Gear
15 3 Reducer Connect Shaft Spacer Ⅱ
16 3 Circlip for Shaft
17 3 Bearing Seat I
18 1 Medium Gear Shaft Spacer I
19 1 Medium Gear Shaft
20 1
Gear Box
21 1
Medium Gear Shaft Spacer II
22 1 Medium Gear
23 1 Reducer Connect Shaft Spacer I
24 1 Deep Groove Ball Bearing
25 1 Circlip for Shaft
26 HL-M1120LD-30-26 1 Reducer Connect Shaft
27 1 Gear Box Side Cover
28 1 Circlip for Shaft
29 1 Bearing Seat II
