FRM- 1120C INSTRUCTION MANUAL
42
Sealer Sales | www.sealersales.com | Tel: 818-718-8818 | E-mail: contact@sealersales.com
Figure 49. FRS-1120W Heating / Cooling Blocks Parts List
Item #
Part #
Quantity Description
Reference Comments
1 2 Cam Shaft Seat 11511011105
2 FRM-1120C-13-36 2 Cam Shaft 11511011104
3 FRM-1120C-13-41 8 Spacing Ring of Pressing Plate 11511011108
4 FRM-1120C-13 2 Adjustment Block Assembly 11511011111 Includes #4, 5
5 FRM-1120C-13 2 Adjustment Block Assembly 11511011112 Includes #4, 5
6 2 Driven Wheel Shaft 11511011102
7 FRM-1120C-12 2 Bearing 6005-2RS (25 x 47x x12) 9105200601052 Includes #7-9
8 FRM-1120C-12 2 Driven Wheel 11511011101 Includes #7-9
9 2 E-Clip 47mm 9746016400047 Includes #7-9
10 Washer-M5x28 2 Washer M5 x 28 x 2 11511010403
11 BS-9B 2 Heater sold as a pair
12 FRM-1120C-9-26 2 Lower Heating Block Shaft 11511011001
13 FRM-1120C-9A-SS 1 Heating Block 11511011002 Includes #13, 15 - sold as a set
14 FRM-1120C-9-24 2 Upper Heating Block Shaft 11511010902
15 FRM-1120C-9A-SS 1 Heating Block 11511010901 Includes #13, 15 - sold as a set
16 FRM-1120C-10 2 Sealing Belt (#1120mm) 9430113112015
17 FRM-1120C-34 1 Thermocouple 9241100021000
18 FRM-1120C-21-27 1 Lower Pressing Wheel Shaft 11511010801 Includes #18-22
19 2 E-Clip 32mm 9746016400032 Includes #18-22
20 2 Pressing Wheel 9105200601022 Includes #18-22
21 2 E-Clip 15mm 9746036400015
22 2 Bearing 6002 ZZ (15 x 32 x 9) 11511010702
23 FRM-1120C-21-22-26 1 Upper Pressing Wheel Shaft 11511010701 Includes #18-21, 23
24 FRM-1120C-8-22 2 Lower Cooling Block Shaft 11511010602
25 FRM-1120C-8-SS 1 Cooling Block 11511010601 Includes #25, 27 - sold as set
26 FRM-1120C-8-18 1 Upper Cooling Block Shaft 11511010502
27 FRM-1120C-8-SS 1 Cooling Block 11511010503 Includes #25, 27 - sold as set
