FR- 770 INSTRUCTION MANUAL
4
How Does the FR-770 Work?
FR-770 is comprised of a stainless steel frame, speed adjusting mechanism, sealing temperature
control system and transmission system. Turning on the heat for the band sealer will cause a
rapid rise in the temperature of the heating blocks. Required temperature and speed can be
adjusted via the temperature controller and speed adjusting device. Plastic material to be sealed is placed on the guide
and conveyor. Conveyor will then take the material between the two heating blocks to fuse the material together.
Material will then pass through the cooling blocks to allow the material to congeal. Finally, material will then pass
through the embossing wheel for a meshed seal line.
The motor drives the sealing belts, drive belts and conveyor simultaneously.
Specifications
FR-770I (Horizontal)
FR-770II (Vertical)
Power
110V/60Hz
Motor / Sealing Power
50W / 300W x 2
Sealing Speed
0-630 inches/minutes
Sealing Width
10mm (Optional 15mm width available)
Temperature Range
0-300˚C (572˚F)
Conveyor Size
38” x 7”
Max Conveyor Load
22-lbs
Min/Max Height of Bag (Vertical Only)
N/A
6” / 12”
Character Size
3x4x9mm / 18PT
Embossing (Optional Feature)
1 line embossing (2 lines available)
3 sections w/ 15 characters/line
Dimensions
33” x 17” x 13”
33” x 15” x 26”
Weight
66lbs
87lbs
Basic Principles
FR-770 is easy to use. To
seal, adjust temperature and
place bag on conveyor
