FR- 770 INSTRUCTION MANUAL
3
Introduction
FR-770 is equipped with an electronic temperature controller and variable speed conveyor to seal all types of
thermoplastic materials (PP, PE, stand up pouches, gusseted bags, moisture barrier bags, etc.). Seals are created using
PTFE bands which maintain high seal quality and produce consistently strong, clean seals on all heat sealable bags.
Because bags are placed on a conveyor system, the width of the bag does not matter. These versatile machines offer
several adjustments which allow them to be used for a wide range of applications. These machines are used
extensively in the food/produce, medical, chemical, cosmetic, and electronic industries. The FR-770 band sealer will
significantly increase efficiency of packaging your products.
There are two configurations for the FR-770 band sealer. The horizontal configuration (FR-770I) is primarily used for
sealing dry materials and when you can lay flat your pouch. The vertical configuration (FR-770II) typically seals small
solid products (ex: powders, grains, coffee) and liquids. In addition, sealing using the vertical configuration also works
best with stand up pouches.
Features of the FR-770 Band Sealer
Your band sealer is equipped with a wide range of standard features and capabilities.
Simple to use – minimal operator training
Rust inhibiting stainless steel construction
Equipped with bag entry guide for easy bag feeding and straight seals
Unit feeds left to right (see CBS-880 for right to left feeding)
Control panel includes industrial grade safety emergency stop switch
10amp protection power surge breaker
Wide seal (8mm) to assure airtight seal / Optional 15mm width sealer model available
PTFE sealing belts
Extended forced-air cooling system with extra wide cooling bars and 6 heat transfer orifices
One pair of brass sealing bars
Sealing method – constant heat
Adjustable 2-way pulley system for optimal stability and embossing clarity
Knurled pressure rolls with variable pressure adjustment
Fast warm up time
PID digital temperature controller 0-300˚C (572˚F) with dual alphanumeric displays (target & current temp)
Motorized rubber conveyor with speed control
Capable of speeds up to 472 inches/minute
Optional pressure embossing coder
Optional digital counter available
