FR- 770 INSTRUCTION MANUAL
14
Operation Set-up
1. Our machines are equipped with a three-prong grounded plug. Make sure the plug is well-connected in the
socket to ensure safe operation.
a. Check that the power supply voltage is consistent with the voltage of the machine
b. Ensure the machine is properly connected to a grounded receptacle. (grounding line is yellow green
double color line)
c. Make sure there is nothing impeding movement of the cable. If the cable appears damaged, replace
immediately
2. Make sure the circuit breaker is in the “ON” position. (Levers pointing up)
3. First time operation. Allow the machine to pre-heat by running at a low temperature for a few minutes. This
would apply if the machine has not been in operation for a long time. The machine can sometimes be damp
from storage or shipment and running at a low temperature will dry out any residual moisture.
4. For some materials, an adjustment to the clearance between the upper heating block and bottom heating block
and upper cooling block and bottom cooling block may be necessary. Adjust the clearance between by turning
the stopping flake clockwise (increase distance) to raise the block our counterclockwise to lower the block
(decrease distance). The clearance should be equal to the thickness of one layer of your material to be packaged.
This will ensure high seal quality and embossing.
Please note that the majority of materials sealed will
NOT need adjustments.
Figure 7. (1) Screw, (2) Stopping Flake, (3) Fastening Screw, (4) Nut
WARNING!
Ensure that the socket has protective grounding wires
Please check the voltage by referring to machine nameplate
Please comply with safety guidelines
