14
7. Troubleshooting
7.1 Sealing head failure and elimination
Problem
Reason
Solution
Tape does not cut
cleanly
Blade is not sharp enough
Replace blade
Adhesive is attached to blade
Clean blade
Tape is not trim
after cutting off
Screw is loose so that knife rest is out
of position as screws
Tighten the screws on the cartridge
Blade spring tightness
Replacement of blade spring
Swing arm tension spring is too loose
Adjusting the swing arm spring
screw
Irregular tooth
shape on the
cutting area
(tearing).
Blade is dull
Replace blade
Blade is installed in wrong direction.
Re-install
Knife spring too weak
Replace spring
The tape has been
cut but the lead is
too long
The knife seat is stuck, the
movement is not flexible or the
elasticity is not enough
Check the screws on each part of
the sealing head to adjust the
tension of the tension spring
Tape cut but
unbonded carton
The main tension spring is too loose,
and the rear rubber roller rebound
speed cannot be synchronized with
the belt speed.
Moderately tighten the main
tension spring screw
Carton is blocked
Main tension spring is too tight
Adjust the main tension spring
Tape roller adjustment nut is too
tight
Adjust the adjustment nut
Improper adjustment of drive unit
and carton height and width
Re-adjust the height and width of
the drive unit
Tape is broken or
cut off while
sealing carton
Two high position of blade
Lower the position of blade
Carton deviation
and box cover
angle after sealing
Carton is not pushed
Before the box is folded, the box
leaves on both sides should be
aligned with the box to be pushed
into the box sealing machine
Too long tape leg
Too low the position of blade
Rise the position of blade
Too short tape leg
Too high the position of blade
Lower the position of blade
Tape adheres to
carton in too
loose
Tension spring on tape head is too
weak
Friction of tape roller is lessened
after dozen times of tape sealing
operation
Adjust the friction of the tape
mount
