CBS- 880 INSTRUCTION MANUAL
4
Optional stand for CBS-880I available
How Does the CBS-880 Work?
CBS-880 is comprised of a stainless steel frame, speed adjusting mechanism, sealing
temperature control system and transmission system. Turning on the heat for the band
sealer will cause a rapid rise in the temperature of the heating blocks. Required temperature
and speed can be adjusted via the temperature controller and speed adjusting device. Plastic material to be sealed
is placed on the guide and conveyor. Conveyor will then take the material between the two heating blocks to
fuse the material together. Material will then pass through the cooling blocks to allow the material to congeal.
Finally, material will then pass through the embossing wheel for a meshed seal line.
The motor drives the sealing belts, drive belts and conveyor simultaneously.
Specifications
CBS-880I (Horizontal)
CBS-880II (Vertical)
Power
110V/60Hz
Motor Power
50W
Sealing Power
300W x 2
Sealing Speed
0-630 inches/minutes
Sealing Width
8mm (Optional 15mm or 30mm width available)
Temperature Range
0-300˚C (572˚F)
Conveyor Size
38” x 7”
Max Conveyor Load
22-lbs
Min/Max Height of Bag
(Vertical Only)
N/A
6” / 12”
Character Size
3x4x9mm / 18PT
Embossing
(Optional Feature)
1 line embossing (2 lines available)
3 sections w/ 15 characters/line
Dimensions
33” x 17” x 13”
33” x 17” x 22”
Weight
60-lbs
66-lbs
Basic Principles
CBS-880 is easy to use. To
seal, adjust temperature and
place bag on conveyor
