CBS- 880 INSTRUCTION MANUAL
3
Introduction
CBS-880 is equipped with an electronic temperature controller and variable speed conveyor to seal all types of
thermoplastic materials (PP, PE, stand up pouches, gusseted bags, moisture barrier bags, etc.). Seals are created
using PTFE bands which maintain high seal quality and produce consistently strong, clean seals on all heat
sealable bags. Because bags are placed on a conveyor system, the width of the bag does not matter. These
versatile machines offer several adjustments which allow them to be used for a wide range of applications.
These machines are used extensively in the food/produce, medical, chemical, cosmetic, and electronic
industries. The CBS-880 band sealer will significantly increase efficiency of packaging your products.
There are two configurations for the CBS-880 band sealer. The horizontal configuration (CBS-880I) is primarily
used for sealing dry materials and when you can lay flat your pouch. We also carry an optional stand for the CBS-
880I which allows the unit to be mobile. The vertical configuration (CBS-880II) typically seals small solid
products (ex: powders, grains, coffee) and liquids. In addition, sealing using the vertical configuration also works
best with stand up pouches.
Features of the CBS-880 Band Sealer
Your band sealer is equipped with a wide range of standard features and capabilities.
Simple to use – minimal operator training
Rust inhibiting stainless steel construction
Unit feeds right to left; Optional left to right feed available (refer to model: FR-770)
Equipped with electronic adjustable speed control
Equipped with bag entry guide for easy bag feeding and straight seals
Control panel includes industrial grade safety emergency stop switch
10amp protection power surge breaker
Wide seal (8mm) to assure airtight seal / Optional 15mm width sealer model available
PTFE sealing belts
Extended forced-air cooling system with extra wide cooling bars and 6 heat transfer orifices
One pair of brass sealing bars
Sealing method – constant heat
Adjustable 2-way pulley system for optimal stability and embossing clarity
Knurled pressure rolls with variable pressure adjustment
Fast warm up time
PID digital temperature controller 0-300˚C (572˚F) with dual alphanumeric displays (target & current
temp)
Motorized rubber conveyor with speed control
Capable of speeds up to 472 inches/minute
Pressure embossing printing coder included
