USER GUIDE
6
Note:
• If the source devices are in standby mode, their power supply should be switched off,
because otherwise the 2 in / 1 out HDMI
®
switch cannot carry out “intelligent” switching.
• If a source is connected or disconnected, this 2 in / 1 out HDMI
®
switch works fully
automatically.
This 2 in / 1 out HDMI
®
switch has many functions that ensure excellent operation.
These functions include:
• Multifunctional switching: automatic or mechanical
• Supports the highest video resolution 1080p
• Supports 250 MHz/2.5 Gbps per channel (7.5 Gbps for all channels) bandwidth
• Supports 12 bits per channel (36 bits for all channels) colour depth
• HDCP transmission
• Supports uncompressed audio, such as LPCM
• Supports compressed audio, such as DTS Digital, Dolby Digital (including DTS-HD and Dolby
True HD)
5. Connection and operation
5.1 Connect the HDMI
®
input sources to the 2 in / 1 out HDMI
®
switch.
5.2 Connect the permanently mounted HDMI
®
cable (pigtail) to the display device.
5.3 Press the “Select” button to select the input source.
Caution: Carefully plug in / pull out the cable.
6. Part diagram
2 1
18 19
INPUT 2 INPUT 1
7. Contents
Check the packaging and ensure that the shipping carton contains the following objects, before
you try to start operating this device:
• 2 in / 1 out HDMI
®
switch
• User Guide
HDVD HDTV
Switch
Gaming console
