USER GUIDE
5
Congratulations and thank you for purchasing this 2 in / 1 out HDMI
®
switch from Schwaiger.
This user guide is designed to help you use and operate the device. Please read through this
user guide carefully and then keep it safe with the device, so that you can consult it should
you experience any problems.
1. Intended use
The 2 in / 1 out HDMI
®
switch is used for switching from two HDMI
®
sources to one HDMI
®
signal output device (e.g. TV) for private use: non-commercial household use. It is intended
solely for this purpose and must be used only for this. Part of this is also the taking into account
of all the information in these operating instructions.
Any other type of use is considered to be unsuitable and may result in property or even
personal damage. This would also result in the immediate loss of guarantee.
The manufacturer disclaims any liability for damages resulting from unintended use.
2. Safety instructions
WARNING!
General safety and maintenance instructions
• This product is an electronic product that must be kept away from children. Therefore, keep
it out of reach of children.
• Protect the product from moisture, water, rain, snow or drizzle and use the product only in
dry environments.
• Do not drop the product or expose it to strong vibrations.
• Do not introduce any objects into the product’s connections or openings.
• Do not disassemble the product into its individual parts. The device does not contain any
parts that require maintenance by the user. Incorrect assembly can cause electric shocks
or malfunctions.
• Clean this product only using a lint-free, damp cloth that is as light as possible and do not
use any aggressive cleaning agents. In doing this, especially ensure that no water (no fluid
or moisture) gets into the product.
3. Introduction
This is a high-performance 2 in / 1 out HDMI
®
switch, which enables the display of two signal
sources on one display. Not only does it enable switching through the pressing of buttons, it
also offers an “intelligent” switching function. Because only one permanently mounted HDMI
®
cable (pigtail) is necessary, this 2 in / 1 out HDMI
®
switch does not only reduce costs, but
also saves time.
This 2 in / 1 out HDMI
®
switch sends High Definition Video (in several resolutions up to 1080p)
and digital audio from each of the two signal sources to display devices. Both inputs are
suitable for the simultaneous connection of High-Definition video sources and compatible with
Blu-Ray, PS4/PS3, Xbox360 etc. The output sends the High Definition audio/video signals to a
high-definition display device.
4. Description of functions
4.1 As soon as the source device is switched on or connected (should be switched on), the
2 in / 1 out HDMI
®
switch automatically selects this source.
4.2 If the source device is switched off or disconnected, the 2 in / 1 out HDMI
®
switch
automatically selects the next source that is switched on, depending on the sequence.
