9 Operation
The product is equipped with a stainless steel container.
The castors allow the product to be highly manoeuvrable.
With wet vacuuming, the suction air flow is switched off by
a safety float valve when the container is full. The product
also has a blowing function.
Please refer to the following descriptions for the function
of the control elements.
ATTENTION
Always make sure the product is fully assembled
before commissioning!
WARNING
Danger of injury!
Only insert the mains plug into the socket when the
product is ready for use.
9.1 Switching the product on/off (Fig. 1)
ATTENTION
Do not use without a filter!
Switching on
1. Insert the mains plug into a properly fused mains
socket.
2. Switch the product on by setting the on/off switch (8)
to the “I” position.
Switching off
1. Switch the product off by setting the on/off switch (8)
to the “0” position.
10 Working instructions
10.1 Suction function
WARNING
Vacuuming glowing ash as well as flamma-
ble, hazardous substances is prohibited.
There is a danger of injury!
ATTENTION
Fine dusts, such as those from cement, soot and plas-
ter, are too fine to be absorbed. There is a risk that it
could get into the motor and damage it.
ATTENTION
Do not use without a filter!
• Place the product on a level, even surface.
• Do not suck up any hot, glowing, flammable, explosive
or hazardous substances. These include hot ash, pet-
rol, solvents, acids or alkalis.
There is a risk of fire and injury.
• If the products heats up switch the product off and pull
out the mains plug. Let the product cool down out-
doors under supervision.
• During breaks, the suction tube can be stored in the
holder on the container lid.
• Fill the container no more than half way so that the
safety float valve (9a) always remains free (Fig. 7).
1. Attach the hose coupling (10a) to the suction connec-
tion (6) (see 8.5.1).
2. Switch on the product (see 9.1).
10.1.1 Dry vacuuming (Fig.1,2)
Note:
Do not use a wet or damp product for dry vacuuming!
1. Insert the paper filter bag (15) into the container (3)
(see 8.4.1).
2. Fit the foam filter (16) (see 8.4.2).
3. Connect the suction coupling (10a) to the suction con-
nection (6) (see 8.5).
4.
Fit the suction pipe (12) tot he handle (11) (see 8.8).
Floor vacuuming:
Connect the suction pipes (12) and one of the nozzles
(13/14).
Vacuuming at table height or in confined spaces:
Connect one of the nozzles (13/14) directly (with no
suction pipe) or with only one suction pipe (12).
5. Hold the suction pipe (10) handle (11) firmly.
6. Switch on the product (see 9.1).
7. Vacuum the area to be cleaned.
8. If necessary, adjust the suction power by sliding the
slider (11a) on the handle (11) forwards and back-
wards.
9. Switch off the product (see 9.1).
10.1.2 Wet vacuuming (Fig.1,2)
Note:
A float integrated in the filter basket ensures that the
suction channel is automatically closed as soon as
the container has reached its maximum capacity. In
this case, the product must be switched off and the
container emptied before operation can be continued.
• Empty the container (3) before wet vacuuming
(see 11.1.1).
• The container (3) is not suitable for storing liquids.
Empty the container (3) after wet vacuuming (see
11.1.1).
1. Remove the paper filter bag (15) from the container
(3) (see 8.4.1).
2. Fit the foam filter (16) (see 8.4.2).
3. Connect the hose coupling (10a) to the suction con-
nection (6) (see 8.5.1).
4. Fit the suction pipe (12) tot he handle (11) (see 8.8).
Floor vacuuming: Connect the suction pipes (12) and
one of the nozzles (13/14). Vacuuming at table height
or in confined spaces: Connect one of the nozzles
(13/14) directly (with no suction pipe) or with only one
suction pipe (12).
5. Hold the suction pipe (10) handle (11) firmly.
6. Switch on the product (see 9.1).
7. Vacuum the area to be cleaned.
8. Switch off the product (see 9.1).
9. Clean the product (see 11.1).
22 | GB www.scheppach.com
