Inclined adjustment of the saw blade
• After loosening the two clamping screws, the saw
blade is continuously adjustable from 90° to 45° (see
scale).
• Check the setting with a test cut.
• Re-adjust the set adjusting if necessary.
Height adjustment of the saw blade
The saw blade is continuously adjustable from 0 to 83
mm cutting height.
• For safe and tidy work, select a small saw blade pro-
jection to the workpiece.
• Adjust the riving knife as shown in Fig. 23.
The riving knife is an important safety device, which
guides the workpiece and prevents the kerf closing
behind the saw blade and the workpiece rebound-
ing. Pay attention to the thickness of the splitting
wedge. The riving knife must not be thinner than the
body of the saw blade and not thicker than its kerf
width.
• Only saw blades with a diameter of 315 mm and a
thickness of 2.4 mm (teeth 3.0 mm) may be used.
• Lower the cover hood onto the workpiece during
every working operation. The cover hood must be
horizontal above the saw blade with each working
operation.
Longitudinal cuts
• For parallel cuts, use the longitudinal stop.
• Use the stop ruler with the high stop side (Fig. 18) for
cutting work over 120 mm and with the low stop side
(Fig. 18) for cutting widths under 120 mm. Guide the
workpiece with the enclosed push stick.
Cross cuts
• Use the sliding carriage for cross cuts and angled
cuts.
Working on circular sawing machines
Cutting wider workpieces, Fig. 24
Width of the workpiece to be machined more than
120 mm
Work process:
• Set the longitudinal stop to suit the intended work-
piece width.
• Ensure that you have a safe hand rest.
Connecting the suction system (Fig. 15)
m WARNING!
Danger of injury for eyes due to swirling chips
• Wear eye protection.
• Only operate the product with a suitable chip extrac-
tion system. Do not use household vacuum clean-
ers.
1. Connect a suitable chip extraction system (not in-
cluded in the scope of delivery) to the suction port
(14).
2. Connect the suction hose (21) of a suitable chip
extraction system (e.g. a multi-purpose suction
device) to the suction port (14).
ATTENTION!
Check and clean the extraction channels at regular
intervals.
10. Transport
By lifting at the front of the machine, it can be easily
relocated in the workshop area to suit the space re-
quirements.
11. Working instructions
After every new setting, we recommend performing a
test cut, in order to check the dimensional settings.
Wait after the saw has been switched on, until the saw
blade has reached full speed, before starting the cut-
ting process.
Secure long workpieces against tipping at the end of
the cutting process (e.g. with roller stand, etc.)
Be careful when cutting.
Only operate the device with an extraction system.
Check and clean the extraction channels at regular in-
tervals.
Make sure that a suitable saw blade for the material to
be cut is selected.
Connect a dust collecting device to the electric tool
when sawing wood.
Do not use saw blades made of high-speed alloy steel
(HSS steel).
Use a push rod or the handle with wooden push block
in order to guide the workpiece safely past the saw
blade. Always keep the push stick or wooden push
block on the electric tool when not in use.
