w ww.practixx.com
16
|
GB
5. Safety instructions
• Only use the tool stand in conjunction with suitable
electric power tools!
• Check the machine base frame for damage each
time before use. Electric power tools shall not be
mounted or operated on damaged support arms /
crossbars.
• Electric power tools must be bolted to the sup-
port arms / crossbars and be secured on the tool
stand!
• Always ensure the machine base frame is se-
cure when setting it up.
• Always ensure that you assume a natural and safe
standing position when working.
• Do not overload the machine base frame! Do not
use the machine base frame for purposes for which
it is not intended.
• Modications or unauthorised changes to the tool
stand and using unapproved parts is prohibited.
• All parts of the tool stand, in particular the safety de-
vices, must be tted correctly in order to guarantee
trouble-free operation.
• Keep the tool stand out of reach of children.
Store the device in a location that is inaccessible to
unauthorised persons and children.
m Attention!
When using electric power tools in conjunction with
the tool stand, the respective machine-specic safety
measures must be implemented as protection against
electric shock, and the risk of injury or re.
Read all of the instructions for the electric power tool
that you intend to mount and operate before using the
tool.
Safety instructions for the electric device mounted
must likewise be observed.
Store these safety instructions safely.
Observe all safety instructions. If you disregard the
safety instructions, you endanger yourself and others.
6. Technical data
Dimensions
1185-2000 x 640 x 900-1000
mm
Table height 815 mm
Height of the side
expansions
910x1020 mm
F 4x Spring washer M8
G 4x Flat head screw M6 x 60 mm
H 4x Washer M6
I 4x M6 spring washers
J 4x M6 hexagonal nuts
Note:
The screws provided to fasten the machine to the uni-
versal base frame are suitable for a large number of
machines. However, it is possible that these are not
suitable for your machine. In this case, you will have
to buy the appropriate screws yourself.
4. Proper use
Always observe the proper use of your machine base
frame.
The tool stand is designed for use with tabletop devices
such as mitre saws, scroll saws, circular table saws, etc.
Electric power tools without suitable mounting holes
are not permitted to be tted to the tool stand and must
not be operated in conjunction with the tool stand.
Electric power tools must be bolted tightly to the tool
stand before starting them up.
The tool stand is also designed as a workpiece support
when working with cross-cut mitre saws, circular table
saws, and other similar electric power tools.
The maximum workpiece length is 3 m.
Additional workpiece supports may have to be used
(e.g. a roller trestle) in order to prevent longer work-
pieces tilting.
Attention: Ensure that the workpiece support is se-
cure and not tilted!
Do not use the machine base frame as a ladder or as
scaolding. Ensure that all handgrips, nuts and screws
are tightened before use. Electric power tools on this
product shall not exceed an overall height of 152 cm.
The maximum payload is 200 kg. Ensure that the ma-
chine base frame is on a level, rm and stable oor.
Any use beyond this is improper use. The manufacturer
is not responsible for the resultant damages, the user
bears this risk alone.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
