2. Knock the clamping sleeve (6) into the axle (4) us-
ing a hammer. (Fig. E)
3. Place the drawbar (2) into the pump and slide the
axle (4) through the drawbar (2) ensuring that the
chain (7) is hanging out behind the drawbar. (Fig. F)
4. Insert the chain (7) through the hole in the axle
(4). (Fig. G)
5. Knock the second clamping sleeve (6) on the other
side into the axle (4) using a hammer. (Fig. F) The
clamping sleeve (6) must protrude from both sides
of the axle (4). (Fig. E)
6. Push the drawbar (2) downwards and carefully pull
out the safety bolts (5). (Fig. I)
7. Push the lever (A) down and push the guide pin of
the chain (7) through the lever (A) guide. (Fig. J)
8. Secure the guide pin by tightening the nut (B).
Note: The nut (B) should not be tightened too
much.
9. Start-up
Make sure that the machine is installed completely and
properly. Before each use, always check:
• The machine for possible damage,
• Whether all screws are tightened,
• The hydraulic oil for leaks
• The oil level
• Visibility of all labels
9.1 Lever positions (Fig. K)
The operating lever (1) installed in the drawbar has 3
positions:
• To lower the fork, lift the operating lever (1) up (pos.
“down”). As soon as it is released, it springs back
into the neutral position.
• The fork position “neutral” is used if the pallet truck
is moved. In this position, the drawbar can move up
and down without the fork moving.
• To lift the fork, push the operating lever (1) down
(pos. “up”). The fork (3) is lifted by the up and down
movement of the drawbar (2).
m Attention! Make sure that the goods are fully on
the pallet. The load-bearing capacity of the prod-
uct must not be exceeded!
10. Cleaning
We recommend that you clean the product directly af-
ter every use.
6. Technical data
Load-bearing capacity 2500 kg
Maximum fork height 190 mm
Minimum fork height 85 mm
Lifting height 105 mm
Fork length 1150 mm
Individual fork width 160 mm
Load wheel diameter 80 mm
Control wheel diameter 180 mm
Weight 62 kg
Subject to technical changes!
7. Unpacking
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating instructions before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
m WARNING!
The product and the packaging material are not
children's toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
8. Assembly / Before commissioning
m ATTENTION!
Always make sure the product is fully assembled
before commissioning!
1. Ensure that the safety bolts (5) are inserted in the
pump.
