20
www.scheppach.com service@scheppach.com +(49)-08223-4002-99 +(49)-08223-4002-58
The specied hand-arm vibration value is based on
grinding with an abrasive sheet. Different applications
may result in different values.
The noise and vibration values were determined ac-
cording to EN 60745-1 and EN 60745-2-3.
The specied vibration value was measured an the
basis of a standard test method and can be used to
compare any kind of power tools.
The specied vibration value can also be used for the
initial evaluation of exposure.
Warning! Depending on how you use the power
tool, the actual vibration values may deviate from
the specied values!
Take measures to protect yourself against vibra-
tions!
Make sure to take into account the entire work
process, i.e. also times when the power tool is
operated without Ioad or switched off! Appropri-
ate measures include the regular maintenance
and care of the power tool and its attachments,
keeping your hands warm, regular breaks and well
planned work processes!
Wear hearing protection.
The effects of noise can cause a loss of hearing.
7. Before starting the equipment
Open the packaging and remove the device carefully.
Remove the packaging material as well as the pack-
aging and transport bracing (if available).
Check that the delivery is complete.
Check the device and accessory parts for transport
damage.
If possible, store the packaging until the warranty pe-
riod has expired.
ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts! There is a risk of swal-
lowing and suffocation!
Before you connect the equipment to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
• Report any damage immediately to the transport
company which was used to deliver the power tool.
• Avoid long supply lines (extension cables).
• Do not operate the power tool in a damp or wet
room.
• The power tool may only be operated in suitable
rooms (well ventilated).
8. Attachment and operation
m Important!
You must fully assemble the appliance before us-
ing it for the rst time!
m Warning! Always pull the power plug before mak-
ing adjustments to the equipment.
8.1. Fitting the telescopic extension (g. 2)
Insert the telescopic extension (10) into the connec-
tion for the telescopic extension (11) and lock it by
twisting as shown in g. 2.
Note: Adjust the Telescopic Plasterboard Sander with
the telescopic extension (10) so that you can work
with it most comfortably. The machine can also be
used without telescopic extension.
8.2. Selecting the right abrasive paper
1. The grain size of the sandpaper is specied on its
rear side. The smaller the specied number, the
coarser the graining.
2. Use sandpaper with coarse grain for rough grind-
ing, and sandpaper with ne grain for nishing.
We recommend sandpapers with aluminium ox-
ide, silicon carbide or other synthetic abrasives.
3. lf you can chose between sandpapers with differ-
ent graining, you should start with coarse grain-
ing sandpaper and complete the grinding process
with the nest possible graining. Thus you will get
good and smooth grinding results.
8.3. Attaching and replacing the sanding paper
(g. 3)
Apply the sandpaper (17) to the grinding plate (1) us-
ing the Velcro strip mechanism.
1. Align the sandpaper (17) with the grinding plate
(1) and press it on evenly.
2. PuII the sandpaper (17) off the grinding plate (1)
and replace it with a new one or another one (g.
3).
8.4. Connection for dust extractor (g. 4, 5)
Warning! Harmful noxious gases may be generated
when e.g. lead-containing paint is processed. These
gases entail a risk for the operator and the persons
in the vicinity! Therefore only use the power tool in
combination with a dust extraction unit, and protect
yourself and other persons in the working area with
additional suitable personal protective equipment!
A large amount of dust is generated when working
with this power tool. The tool is equipped with inte-
grated dust extraction, which constantly extracts the
grinding dust when the tool is switched on
Insert the hose adaptor (14) into the connection for
dust extraction (9 or 111) and lock it by twisting as
shown in g. 4.
