8.1 Wall mounting of the charger (27)
(Fig. 1)
WARNING
– Before wall mounting, make sure that there are no
lines in the wall in the area of the drill holes that
could be damaged.
– Lay the mains cable so that it does not obstruct you
and no one can accidentally pull on it.
– Children must not play with the product, even if it is
hanging on the wall.
– Mounting behind doors and their swinging range is
not recommended, as there is a risk of tearing off or
otherwise damaging the product.
WARNING
The product must never be operated on a combustible
surface.
WARNING
Never attach the product to a wet surface.
WARNING
Ensure adequate ventilation.
* = not included in the scope of delivery!
The battery charger (27) has two holes on its back for wall
mounting with two screws*. It can be hung on a wall, tak-
ing into account the safety instructions and the dimen-
sions given.
8.2 Fitting/replacing the saw blade (12)
(Fig. 3)
WARNING
Tool attachments may be sharp and become hot during
use. Always wear protective gloves when handling the
tool attachments.
CAUTION
Keep your hands away from the tool attachment when
the product is in operation.
ATTENTION
The saw blade is not pre-mounted!
1. Set the cutting depth scale (5) to 0mm and lock the
wing screw (17).
8.2.1 Fitting the saw blade (12)
CAUTION
An incorrectly installed saw chain leads to uncontrolled
cutting behaviour by the product!
When fitting the saw chain, observe the prescribed run-
ning direction!
WARNING
Make sure that the saw blade is suitable for the speed
of the tool.
1. Swing back the protective cover (15) with the retract-
ing lever (16) and place the saw blade (12) from be-
low into the fixed protective cover (11) and onto the
spindle.
2. Place the flange (13) on the saw blade (12).
3. Press the spindle lock (22) and fix the saw blade (12)
with the Allen screw (14). Use the Allen key (23).
8.2.2 Dismantling the saw blade (12)
1. Swing back the protective cover (15) with the retract-
ing lever (16) and place the product on a level sur-
face.
2. Press and hold the spindle lock (22).
3. Loosen the Allen screw (14) with the Allen key (23).
4. Remove the Allen screw (12) and the flange (13).
5. Lift the product, hold back the protective cover (15)
and carefully remove the saw blade (12) downwards
from the fixed protective cover (11).
8.3 Inserting/removing the battery (19)
into/from the battery mount (1)
(Fig. 4)
Inserting the battery
1. Push the battery (19) into the battery mount (1). The
battery (19) clicks into place audibly.
Removing the battery
1. Press the unlock button (18) of the battery (19) and
remove it from the battery mount (1).
8.4 Fitting the parallel stop (24) (Fig. 5)
1. Loosen the wing screw (20) for the parallel stop mount
(21) and insert the parallel stop (24) into the parallel
stop mount (21).
2. Set the desired cutting width using the scale (25) on
the parallel stop (24) and the recess in the base plate
(7).
3. Tighten the wing screw (20) for the parallel stop
mount (21).
9 Operation
The cordless circular saw has an overload protection and
a spindle lock.
Please refer to the following description for the function of
the controls.
WARNING
Danger of injury!
Remove the battery from the power tool before carrying
out any work on the power tool (e.g. maintenance, tool
change, etc.) and when transporting and storing it.
There is a risk of injury if the on/off switch is operated
unintentionally.
GB | 25www.scheppach.com
