• When ordering please provide our article number as
well as type and year of manufacture for the product.
8 Before commissioning
8.1 Wall mounting of the charger (13)
(Fig. 1)
WARNING
– Before wall mounting, make sure that there are no
lines in the wall in the area of the drill holes that
could be damaged.
– Lay the mains cable so that it does not obstruct you
and no one can accidentally pull on it.
– Children must not play with the product, even if it is
hanging on the wall.
– Mounting behind doors and their swinging range is
not recommended, as there is a risk of tearing off or
otherwise damaging the product.
WARNING
The product must never be operated on a combustible
surface.
WARNING
Never attach the product to a wet surface.
WARNING
Ensure adequate ventilation.
* = not included in the scope of delivery!
The battery charger has two holes on its back for wall
mounting with two screws*. It can be hung on a wall, tak-
ing into account the safety instructions and the dimen-
sions given (see Fig. 1).
8.2 Mounting the belt clip (11)
1. During work breaks, the product can be hooked onto
the belt with the integrated belt clip (11).
2. Screw the belt clip (11) with the screw (12) to the right
or left screw-on point on the product, as required. Use
a Phillips screwdriver for this (not included in the
scope of delivery).
Note:
Make sure that the product is switched off and secured
against being switched on.
9 Operation
The cordless drill with 2-gear transmission has a 25+1
level torque adjustment, clockwise/anticlockwise rotation,
quick-release chuck and an LED work lamp.
Please refer to the following descriptions for the function
of the controls.
WARNING
Danger of injury!
Remove the battery from the power tool before carrying
out any work on the power tool (e.g. maintenance, tool
change, etc.) and when transporting and storing it.
There is a risk of injury if the on/off switch is operated
unintentionally.
ATTENTION
Make sure that the ambient temperature does not ex-
ceed 50°C and does not fall below -20°C during work.
ATTENTION
The product is part of the 20V IXES series and may on-
ly be operated with batteries of this series. Batteries
may only be charged with battery chargers of this se-
ries. Observe the manufacturer's instructions.
9.1 Inserting/removing the battery (5)
in the battery mount (6) (Fig. 2)
Inserting the battery
1. Put the rotational direction switch (10) in the middle
position (lock).
2. Push the battery (5) into the battery mount (6). The
battery (5) clicks into place audibly.
Removing the battery
1. Press the unlock button (7) of the battery (5) and re-
move it from the battery mount (6).
9.2 Check the charge status of the
battery
The charge status indicator (28) indicates the charge sta-
tus of the battery (5).
The charge status of the battery is indicated by the corre-
sponding LED light lighting up.
1. Press the charge status indicator button on the battery
(27).
LED on the battery Charging status
red-orange-green Battery full
red-orange Battery partially charged
red Battery empty
20 | GB www.scheppach.com
