Je bekijkt pagina 19 van 36
WARNING
Follow the safety and charging instructions
and correct usage given in the instruction
manual of your 20V IXES Series battery and
charger. A detailed description of the
charging process and further information are
provided in this separate manual.
6 Technical data
Rated voltage 20 V
Idle speeds n
0
• Gear 1
• Gear 2
0 - 400 rpm
0 - 1550 rpm
Max. torque 50 Nm
Chuck span Ø 1.5 - 13 mm
Weight (without battery) 1.2 kg
Drilling diameter for wood max. 30 mm
Drilling diameter for steel max. 13 mm
Protection category IPX0
Battery charger SBC2.4A
Input
Rated voltage 230 – 240 V~
50 Hz
Rated power consumption 65 W
Fuse (internal) 3.15 A
Output
Rated voltage 21.5 V
Rated current 2.4 A
Protection class II (Double insulation)
Loading time:
2 Ah approx. 60 min
4 Ah approx. 120 min
Battery (Li-Ion) SBP2.0
Number of battery cells 5
Rated voltage max. 20 V
Capacity 2.0 Ah
Power 40 Wh
Max. temperature. 50°C
Charging process temperature 4 °C – 40 °C
Operation temperature -20 °C – 50 °C
Storage temperature 0 °C – 45 °C
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Noise data
Sound pressure L
pA
72.1 dB
Measurement uncertainty K
pA
5 dB
Sound power L
wA
83.1 dB
Measurement uncertainty K
wA
5 dB
Vibration parameters (hand/arm vibration)
Vibration a
h
< 2.5 m/s
2
Measurement uncertainty K 1.5 m/s
2
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
WARNING
The noise emission values and vibration
emission value can vary from the specified
values during the actual use of the power
tool, depending on the type and the manner
in which the electric tool is used, and in par-
ticular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
GB | 19www.scheppach.com
